Low Profile Scissor Lift

Low profile scissor lift for sale

Low profile scissor lift when the platform is all set up, its height is very Low, so as to facilitate the loading and unloading of goods. Generally, the hydraulic pump of the lifting platform is under the table, and the Low profile scissor lift is external to the hydraulic mechanism, which saves a lot of space and makes the table very Low.

DFLIFT is a professional manufacturer of Low profile scissor lift; we will provide you with the best quality products and services welcome to consult.

low profile scissor lift

Rated load:500kg 1000kg 1500kg 2000kg

The minimum height: 180mm

The highest height: 1000mm

Power supply: single-phase alternating current

U-shaped electric low profile scissor lift price

U shaped electric low profile scissor lift

Rated load:500kg 1000kg 1500kg 2000kg

The minimum height: 180mm

The highest height: 1000mm

Power supply: single-phase alternating current

The fixed lifting platform is mainly used for large quantity loading, unloading and handling of goods in factories, warehouses, stockyards, stations, wharves and grain warehouses. It can be used with forklift and truck to load and unload goods quickly from container or truck.

Electric low profile scissor lift specifications

Tables

Model

Capacity

Min. /max. table height

Table Size

Base Size

Lifting Time

Power

Net Weight

kg

mm

mm

mm

s

/

kg

DF1001C

1000

85/860

1450*1140

1325*1074

25

380V/50Hz

357

DF1002C

1000

85/860

1600*1140

1325*1074

25

380V/50Hz

364

DF1003C

1000

85/860

1450*800

1325*734

25

380V/50Hz

326

DF1004C

1000

85/860

1600*800

1325*734

25

380V/50Hz

332

DF1005C

1000

85/860

1600*1000

1325*734

25

380V/50Hz

352

DF1501C

1500

105/870

1600*800

1325*734

30

380V/50Hz

302

DF1502C

1500

105/870

1600*1000

1325*734

30

380V/50Hz

401

DF1503C

1500

105/870

1600*1180

1325*734

30

380V/50Hz

415

DF2001C

2000

105/870

1600*1180

1427*1114

35

380V/50Hz

419

DF2002C

2000

105/870

1600*1000

1427*734

35

380V/50Hz

405

Electric low profile scissor lift product description

European brand pump station is optional for heavy duty design

A safety bar device is installed under the table to stop falling when encountering obstacles under the table

The internal power supply is equipped with relief valve and compensation flow switch. The relief valve prevents overload and compensates the flow switch to control low speed. Hydraulic system equipped with explosion-proof valve, when the pipeline burst, can prevent the flat car down

Electric low profile scissor lift is designed to prevent clip injury

All shaft points and bushing adopt automatic lubrication design

Removable lifting ring, easy to operate and install

Electric low profile scissor lift low level design and different slope boards for easy to use
