Self-propelled Scissor Lift

Self-propelled scissor lift platform is a kind of multi-functional lifting and loading equipment. The lifting height varies from 1 m to 20 m, the platform can be customized according to individual requirements. Self-propelled scissor lift platform is generally made of high-strength alloy, which makes the deflection and swing of the lift extremely small. With functions of automatic walking, walking three optional power control and the accumulator control, able to work under different conditions, without external power supply, handle control, speed adjustable, mobile and flexible, easy to operate, lift freely, only one person can complete forward, backward, steering, fast, slow to walk and up and down movement, save work and effort. Especially suitable for station, dock, airport, power plant, stadium, large enterprises and other large range of aerial work, is currently the most ideal aerial work equipment in the world.

Self-propelled scissor lift manufacturer:

scissor lift manufacturer

Rated Loading Capacity: 320kg 480kg

Min. Lifting Height: 800mm

Max. Lifting Height:16000mm

Main Material: High duty steel

After-sales Service Provided: Field installation, commissioning and training

Platform: Anti-skid Checkered Plate

Voltage: 110V,220V,380V, customized

Self-propelled scissor lift parameter table

Model

SPS0.3-6

SPS0.3-8

SPS0.3-10

SPS0.3-12

Platform height

6m

8m

10m

12m

Work height

8m

10m

12m

14m

Load capacity

300kg

300kg

300kg

300kg

Dimension

2.48*0.81*1.87

2.48*0.81*1.89

2.48*1.5*1.92

2.48*1.15*2.04

Platform size

2.27*0.81m

2.27*0.81m

2.27*1.12m

2.27*1.12m

Extension deck

0.90m

0.90m

0.90m

0.90m

Drive motor

24V/1.5KW

24V/1.5KW

24V/1.5KW

24V/1.5KW

Lift motor

24V/3.3KW

24V/3.3KW

24V/4.5KW

24V/4.5KW

Travel speed

4.0km/h

Wheel

Φ300*100mm

Weight

2125kg

2180kg

2965kg

2910kg

Self-propelled scissor lift Suitable for indoor and outdoor cleaning (ceiling, curtain wall, glass window, eaves, rain cover, chimney, etc.), installation and maintenance of billboards, installation and maintenance of street lamps and traffic signs, etc., which are favored by large shopping malls, subway stations, railway stations, families and offices!

DFLIFT Luxury Hydraulic Self-propelled lifts (Main parts imported)

Self-propelled scissor lift Main Parts Origin

Name Origin Brand
DC motor Korea Hydra Power(5.0ml/r)
Hydraulic pump station Korea Hydra Power
Block assemble (include  solenoid valve) Italy SANT
BK Brake USA White
RE Motor USA White(375ml/r)
Brake release pump USA White
Battery USA Trojan

Mini scissor lift for sale:

Mini scissor lift platform body beautiful, small vehicle, flexible operation; The main engine is electric drive wheel steering, with its own walking, lifting, steering and other functions. It adopts imported hydraulic components, equipped with explosion-proof pipe device and emergency descending device, and the walking steering is realized by electric drive machine, with low noise and no air pollution. Mini scissor lift Choose durable, not easy to scratch the ground, not easy to stick debris, skid - proof non - trace tires; Under the premise of ensuring safety and reliability, the product control mode and procedure are optimized, and the operation is more humanized.

Mini scissor lift
Mini scissor lift parameters

Rated Loading Capacity: 230kg 300kg

Max. Lifting Height:5.8m 19 ft.

Platform: Anti-skid Checkered Plate

Voltage: 110V,220V,380V, customized

Automatic scissor lift tables use for working at different heights by oneself.

DFLIFT Self-propelled scissor lift Introduce

  1. Self-propelled scissor lift takes storage battery as the power source, low noise and no emission when working.
  2. The steering wheel can turn 90°, easy to move in small space.
  3. Large work table can extend on one size or both sides, foldable guardrail, easy to transport.
  4. Hydraulic motor and electric motor can be selected, hydraulic pump station can chose exported brand of America, Italy, and Korea, etc.
  5. Lift height from 4m to 12m, load capacity can be 300kg, 500kg, can be custom-made.

Why choose us DFLIFT Self-propelled scissor lift?

  1. Service concept: Attention to contract, guarantee quality, on-time delivery and keeping promises.
  2. Pre-sale service: Free technical advice, to meet the needs of customers.
  3. Sale service: Free on-site installation service and operating guidance for user.
  4. After-sale service: Free 1 year warranty, 48 hours door-to door maintenance with cost price.
  5. Quick responses: 24-hours hotline, to solve your problem in the shortest time.
